Mechanical | |
---|---|
Dimensions | Without mount: O82 x 88.3 mm (O3.23 x 3.48") With wall mount: O82 x 153 mm (O3.23 x 6.02") |
Weight | Without mount: 628 g (1.38 lb) With wall mount: 765 g (1.69 lb) |
Enclosure materials | Aluminum alloy, polycarbonate |
Mounting materials | Wall mount: aluminum alloy Pole mount: aluminum alloy |
Weatherproofing | IP65 |
Resistance | IK04 |
Optics | |
Sensor | 5 MP CMOS sensor |
Lens | Fixed focal length |
View angle | H: 84.7°, V: 46.2°, D: 99° |
Night mode | IR LED illumination and an IR cut filter |
Video | |
Video compression | H.264, MJPG |
Resolution | 4MP (2688 x 1512), 16:9 aspect ratio |
Maximum frame rate | 30 FPS |
Image settings | Brightness, contrast, sharpness, saturation, noise reduction, 50/60 Hz |
System | |
Processor specs | Quad core Arm® Cortex®-A53 based chip |
Memory information | 2 GB LPDDR4 |
Management interface | UniFi Protect application |
Networking interface | 10/100/1,000 MbE RJ45 |
Flash memory support | 8GB eMMC |
Max. power consumption | 7.68W |
Power method | PoE |
Supported voltage range | 37-57VDC |
LED | R/G/B/W ring |
Button | Factory reset |
Mounting | Wall, pole mount (included) |
Operating temperature | -20 to 40° C (-4 to 104° F) |
Operating humidity | 10 to 90% noncondensing |
Certifications | FCC, IC, CE |
Audio | |
Microphone | Yes (can be disabled) |
Software | |
UniFi OS application | UniFi Protect |
Mobile app | UniFi Protect (iOS and Android) |
![]() |
