Gigabyte GV-R65XTEAGLE-4GD
Rx6500 xt eagle 4g

Graphics Processing

Radeon™ RX 6500 XT

Core Clock

Boost Clock* : up to 2815 MHz
Game Clock* : up to 2610 MHz

Stream Processors

1024

Process Technology

6 nm

Memory Clock

18000 MHz

Memory Size

4 GB

Memory Type

GDDR6

Memory Bus

64 bit

Memory Bandwidth (GB/sec)

144 GB/s

Card Bus

PCI-E 4.0

Digital max resolution

7680x4320

Multi-view

2

Card size

L=192 W=117 H=38 mm

PCB Form

ATX

DirectX

12 Ultimate

OpenGL

4.6

Recommended PSU

400W

Power Connectors

6 pin*1

Output

DisplayPort 1.4a *1
HDMI 2.1 *1

Accessories

Quick guide

Note

* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
