120mm, PFC: aktív, 80%, 4+4-pin tápcsatlakozó: 1db, 6+2-pin VGA csatlakozó: 2db, fekete120mm, PFC: aktív, 80%, 4+4-pin tápcsatlakozó: 1db, 6+2-pin VGA csatlakozó: 2db, feketeGarancia: 36 Hónap Technical Spec
| Model | PF500X |
| Model No | PF500X-HD |
| Total Output | 500W |
| Type | ATX12V V2.52 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Efficiency certification | 80PLUS 230 EU Bronze/CYBENETICS Bronze /CYBENETICS A 230V/PPLP 230V Bronze |
| Fan Size | 120mm |
| Fan Bearing | Longlife HYB |
| Topology | Active PFC+DC to DC |
| Capacitors | Taiwanese + Japanese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(75% Load) |
| Efficiency | ≥88% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/OCP/SCP/OTP/UVP/SIP/NLO |
| Operation Temperature | 0-40°C |
| Regulatory | CE/TUV-RH/CCC/RCM/KC |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/?? RoHS/Triman |
| MTBF | 40,000 Hours |
