| Model Variations | S1934-HBK: with Height Adjustable Stand, black S1934-HGY: with Height Adjustable Stand, gray S1934-TBK: with Tilt Stand, black S1934-TGY: with Tilt Stand, gray S1934-FBK: without stand, black S1934-FGY: without stand, gray Note: Stand is removable |
| Panel | |
| Type | IPS |
| Backlight | LED |
| Size | 19" / 48 cm |
| Native Resolution | 1280 x 1024 (5:4 aspect ratio) |
| Viewable Image Size (H x V) | 374.8 x 299.8 mm |
| Pixel Pitch | 0.293 x 0.293 mm |
| Display Colors | 16.77 million from a palette of 1.06 billion |
| Viewing Angles (H / V, typical) | 178° / 178° |
| Brightness (typical) | 250 cd/m 2 |
| Contrast Ratio (typical) | 1000:1 |
| Response Time (typical) | 14 ms (gray-to-gray) |
| Color Gamut (typical) | sRGB |
| Video Signals | |
| Input Terminals | DisplayPort (HDCP 1.3), DVI-D (HDCP 1.4), D-Sub mini 15 pin |
| Digital Scanning Frequency (H / V) | 31 - 64 kHz / 59 - 61 Hz |
| Analog Scanning Frequency (H / V) | 31 - 64 kHz / 55 - 61 Hz |
| Sync Formats | Separate |
| Audio | |
| Speakers | 0.5 W + 0.5 W |
| Input Terminals | Stereo mini jack, DisplayPort |
| Output Terminals | Headphones (Stereo mini jack) |
| Power | |
| Power Requirements | AC 100 - 240 V, 50 / 60 Hz |
| Typical Power Consumption | 9 W |
| Maximum Power Consumption | 21 W |
| Power Save Mode | 0.5 W or less |
| Features & Functions | |
| Preset Modes | Color mode (User1, User2, sRGB, Paper, DICOM) |
| Auto EcoView | Yes |
| OSD Languages | English, French, German, Italian, Japanese, Simplified and Traditional Chinese, Spanish, Swedish |
| Physical Specifications | |
| Dimensions (Landscape, W x H x D) | S1934-H: 405 x 406.5 - 506.5 x 205 mm S1934-T: 405 x 414 x 205 mm |
| Dimensions (Portrait, W x H x D) | 334 x 442 - 542 x 205 mm |
| Dimensions (Without Stand, W x H x D) | 405 x 334 x 61.5 mm |
| Net Weight | S1934-H: 5.6 kg S1934-T: 4.6 kg |
| Net Weight (Without Stand) | 3.8 kg |
| Height Adjustment Range | S1934-H: 100 mm S1934-T: - |
| Tilt | S1934-H: 30° Up, 0° Down S1934-T: 30° Up, 5° Down |
| Swivel | S1934-H: 35° Right / 35° Left S1934-T: - |
| Pivot | S1934-H: 90° S1934-T: - |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Environmental Requirements | |
| Operating Temperature | 5 - 35 °C |
| Operating Humidity (R.H., non condensing) | 20 - 80 % |
| Certifications & Standards (Please contact EIZO for the latest information.) | TCO Certified Generation 8, TUV/Ergonomics, TUV/GS, RCM, CE, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, EAC |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | |
| Signal Cables | DVI-D (2 m) , D-Sub mini 15 pin (1.8 m) |
| Others | AC power cord (2 m), audio cable (2.1 m), Screw for VESA mount x4, CD-ROM (PDF user's manual), setup guide |
| Warranty | Five Years |
| Dimension Drawing |
|
|
