Startech SV565UTPUEU
Vga kvm console extender

USB2.0 bemenet: 2db, USB2.0 kimenet: 2db, D-Sub bemenet: 1db, D-Sub kimenet: 1db, ethernet port: 1dbUSB2.0 bemenet: 2db, USB2.0 kimenet: 2db, D-Sub bemenet: 1db, D-Sub kimenet: 1db, ethernet port: 1db

The SV565UTPUEU USB VGA KVM Console Extender over CAT5 UTP (500 ft) lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 500 ft (150 m) away. PC connection cables are included with this product for a ready out of the box solution.

You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

• Low cost way to convert existing standard KVM units into remotely accessible hardware extending your hardware’s capabilities
• Maintain network security with long distance local access without being exposed over IP
• Broad support for newer USB keyboards, mice, and even most combo/wireless configurations

Audio	No
KVM Ports	2
Multi-Monitor	No
PC Interface	USB
PC Video Type	VGA
Rack-Mountable	No
Performance
IP Control	No
Max Transfer Distance	150 m (492 ft)
Supported Resolutions	1280 x 1024 @ 300ft/ 100m 1024 x 768 @ maximum cable length
Connector(s)
Console Interface(s)	2 - VGA (15 pin; High Density D-Sub) Female
	4 - USB A (4 pin) Female
Host Connectors	2 - VGA (15 pin; High Density D-Sub) Female
Other Interface(s)	2 - RJ-45 Female
Software
OS Compatibility	OS independent; No software or drivers required
Special Notes / Requirements
Note	Product weights/measurements indicate a single unit only (either Host or Remote)
Power
Center Tip Polarity	Positive
Input Current	0.2A
Input Voltage	110 ~ 240 AC
Output Current	0.6A
Output Voltage	9 DC
Plug Type	M
Power Source
