Display
Size 43inch
Panel Type VA
Response Time 6.5ms
Aspect Ratio 16:9
Display Area 941.184(H)×529.416(V)mm
Pixel Pitch 0.2451×0.2451mm
Resolution 3840(H)×2160(V)
Refreshing Frequency 60Hz
Display Color 1.07B(10bit)
NTSC 72%
Contrast Ratio 5000:1
Viewing Angle 178°(H/V)
Back Light Unit DLED
Brightness with glass(min) 400cd/m² Brightness with glass(typ) 450cd/m² Life Time ≥30000 Hours
Operating System
System Version Android 8.0
3
RAM 3G
ROM 16G
CPU A73×2+A53×2
GPU Mali-G51MP2
Audio
Sound Channel 2.0
Output Power 2×8W
Power
Power Requirements 100-240V~50/60Hz 1.5A
Overall Power(Max.) 150W
Standby Power ≤0.5W
I/O Port
HDMI IN 2
HDMI OUT (optional) 1
USB 2.0 2
VGA IN 1
AUDIO IN 1
AUDIO OUT 1
SPDIF 1
RS232 1
RJ45 IN 1
Physical Specifications
Dimension L×H×D 964.6×552.5×71.4mm
Dimension (package) L×W×H 1056×156×672mm
Thickness of machine and wall mount 95.4mm(WIB4722A)
Wall-hanging Screw Spec M6×12mm
VESA 200×200mm
Net Weight 9.35Kg
Gross Weight 12.20Kg
Accessories
Power Cord ×1
Remote Control ×1
Environmental Conditions
Operation Temperature 0?~40?
Operation Humidity 10%~90%RH
Storage Temperature -20?~60?
Storage Humidity 10%~90%RH
Altitude Below 5000 meters
Optional Module
Wireless Module USB WIFI Dongle: 8822BU
