General Specifications
Printer Type | |
Print Method | |
Memory Capacity | Standard | |
Machine display | |
Power Source | |
Power Consumption (Average) | Peak | |
Printing *1 *2 | (HL-L2400DW/HL-L2400DWE/HL-L2402D/HL-L2442DW) Approximately 440 W at 25 °C (HL-L2445DW/HL-L2447DW/HL-L2460DN/HL-L2865DW) Approximately 470 W at 25 °C
|
Printing (Quiet Mode) *1 *2 | |
Ready *1 *2 | |
Sleep *1 *2 | |
Deep Sleep *1 *2 | |
Power Off *3 *4 | |
Dimensions (Typical outline view) | Unit: mm |
Weight (with supplies) | |
Noise Level | Sound Pressure *5 | Printing | |
Printing (Quiet Mode) | |
Ready | |
Sound Power | Printing *5 | |
Printing (Quiet Mode) | |
Ready | |
Temperature | Operating | |
Storage | |
Humidity | Operating | |
Storage | |
*1
Measured when the machine is connected to the USB interface.
*2
Measured when the machine is connected using the same network connection as the ENERGY STAR Ver. 3.1 test method.
*3
Measured according to IEC 62301 Edition 2.0.
*4
Power consumption varies slightly depending on the usage environment.
*5
Measured in accordance with the method described in ISO 7779.
Print Media Specifications
Paper Input | Paper Tray (Standard) | Paper Type | |
Paper Size | A4, Letter, B5 (JIS), B5 (ISO), A5, A5 (Long Edge), B6 (JIS), A6, Executive, 16K (195x270 mm), A4 Short (270mm Paper)
|
Paper Weight | |
Maximum Paper Capacity | |
Manual Feed Slot | Paper Type | Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
|
Paper Size | Width: 76.2 to 215.9 mm Length: 127 to 355.6 mm Envelope: COM-10, DL, C5, Monarch
|
Paper Weight | |
Maximum Paper Capacity | |
Paper Output *2 | Face Down Output Tray | |
Face Up Output Tray | |
2-sided | Automatic 2-sided Printing | Paper Type | |
Paper Size | |
Paper Weight | |
*1
For paper of 105 g/m2 and above, open the back cover to use the face up output tray.
*2
For labels, we recommend removing the printed sheets from the output paper tray immediately after they exit the machine to avoid the possibility of smudging.
*3
Calculated with 80 g/m2 in a temperate, non humid environment.
Printer Specifications
Automatic 2-sided Print | |
Emulation | (HL-L2460DN/HL-L2865DW) PCL6
|
Resolution | |
Print Speed *1 *2 | 1-sided Print *3 | (HL-L2400DW/HL-L2400DWE/HL-L2402D/HL-L2442DW) Up to 30 pages/minute (A4 size) Up to 32 pages/minute (Letter size) (HL-L2445DW/HL-L2447DW) Up to 32 pages/minute (A4 size) Up to 34 pages/minute (Letter size) (HL-L2460DN/HL-L2865DW) Up to 34 pages/minute (A4 size) Up to 36 pages/minute (Letter size)
|
2-sided Print | (HL-L2400DW/HL-L2400DWE/HL-L2402D/HL-L2442DW) Up to 15 sides/minute (Up to 7.5 sheets/minute) (Letter or A4 size) (HL-L2445DW/HL-L2447DW/HL-L2460DN/HL-L2865DW) Up to 16 sides/minute (Up to 8 sheets/minute) (A4 size) Up to 17 sides/minute (Up to 8.5 sheets/minute) (Letter size)
|
First Print Time *4 | |
*1
The print speed may change depending on the type of document you print.
*2
The print speed may be slower when the machine is connected by wireless LAN.
*3
These print speeds are for 1-sided printing and measured in accordance with ISO/IEC 24734.
*4
From Ready mode and standard tray.
Interface Specifications
USB | Type: USB Type-B receptacle Version: USB 2.0 High-Speed *1 *2 Use a USB 2.0 interface cable that is no more than 2 metres long.
|
LAN | |
Wireless LAN | (HL-L2400DW/HL-L2400DWE/HL-L2442DW/HL-L2445DW/HL-L2447DW/HL-L2865DW) IEEE 802.11a/b/g/n (Infrastructure Mode) IEEE 802.11a/g/n (Wi-Fi Direct®)
|
*1
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
*2
Third party USB hub devices are not supported.
*3
Use a straight-through Category 5 (or greater) twisted-pair cable.
Supported Protocols and Security Features
Supported protocols and security features may differ depending the models.
Ethernet
10Base-T/100Base-TX
Wireless LAN (2.4 GHz)
IEEE 802.11b/g/n (Infrastructure Mode), IEEE 802.11g/n (Wi-Fi Direct)
Wireless LAN (5 GHz)
IEEE 802.11a/n (Infrastructure Mode), IEEE 802.11a/n (Wi-Fi Direct)
Protocols (IPv4)
ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print)
Protocols (IPv6)
NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, Web Services (Print)
Network Security (Wired)
SMTP-AUTH, SNMP v3,SSL/TLS(SMTP,HTTP,IPP), 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth(SMTP, POP3, IMAP4)
Network Security (Wireless)
SMTP-AUTH, SNMP v3,SSL/TLS(SMTP,HTTP,IPP), 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), OAuth(SMTP, POP3, IMAP4)
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) (Wi-Fi Direct supports WPA2-PSK (AES) only) , WPA3-SAE (AES)
Wireless Certification
Wi-Fi Certification Mark License (WPA3™ - Enterprise, Personal), Wi-Fi Protected Setup™ (WPS) Identifier Mark License, Wi-Fi CERTIFIED™ Wi-Fi Direct
Computer Requirements Specifications
Supported Operating Systems And Software Functions
Computer Platform & Operating System Version | Computer Interface | Processor | Hard Disk Space to Install *1 |
USB *2 | Wired LAN | Wireless LAN | For Drivers | For Applications (including Drivers) |
Windows 10 Home / 10 Pro / 10 Education / 10 Enterprise | Printing | 32 bit (x86) or 64 bit (x64) processor | 50 MB | 1.6 GB |
Windows 11 Home / 11 Pro / 11 Education / 11 Enterprise | 64 bit (x64) processor |
Windows Server 2012 | Printing | 64 bit (x64) processor | 50 MB | 50 MB |
Windows Server 2012 R2 |
Windows Server 2016 |
Windows Server 2019 |
Windows Server 2022 |
macOS v11 *3 | Printing | 64 bit processor | N/A | 500 MB |
macOS v12 *3 |
macOS v13 *3 |
Chrome OS | Printing | N/A | N/A | N/A |
*1
An Internet connection is required to install the software if the installation disc is not supplied.
*2
Third party USB ports are not supported.
*3
macOS Disclaimer
AirPrint capable: Printing via macOS requires the use of AirPrint. Mac drivers are not provided for this machine.
