| Audio | Yes |
| Cabling | HDMI |
| Industry Standards | High Speed HDMI®, HDCP, EDID |
| Ports | 4 |
| Performance | |
|---|---|
| Maximum Cable Length | 16.4 ft [5 m] |
| Maximum Digital Resolutions | HDTV 1080p / PC 1920x1200 |
| Supported Resolutions | 1080p (1920 x 1080) / VGA (640 x 480) / SXGA (1280 x 1024) / UXGA (1600 x 1200) / WUXGA (1920 x 1200) |
| Wide Screen Supported | Yes |
| Connector(s) | |
| Connector A | 1 - 3.5 mm Mini-Jack (3 Position) Female |
| 1 - HDMI (19 pin) Female | |
| Connector B | 4 - 3.5 mm Mini-Jack (3 Position) Female |
| 4 - HDMI (19 pin) Female | |
| Indicators | |
| LED Indicators | 1 - Power (Green) / Input Signal (Blue) |
| 4 - Green Port signal indicator | |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.8A |
| Input Voltage | 110 ~ 240 AC |
| Output Current | 1.5A |
| Output Voltage | 12 DC |
| Power Source | AC Adapter Included |
| Environmental | |
| Humidity | 0%~80% |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Steel |
| Product Height | 1.7 in [44 mm] |
| Product Length | 8.7 in [220 mm] |
| Product Weight | 37.9 oz [1074 g] |
| Product Width | 5.3 in [135 mm] |
| Packaging Information | |
| Shipping (Package) Weight | 3.5 lb [1.6 kg] |
| What's in the Box | |
| Included in Package |






|
