Audio | Yes |
Chipset ID | MCT Trigger 5 T5-302 |
Industry Standards | SuperSpeed USB 3.0, USB 2.0 |
Memory | 16MB DDR II |
Output Signal | HDMI |
USB Pass-Through | Yes |
Performance | |
---|---|
Audio Specifications | 2-Channel Stereo (48Khz) |
General Specifications | This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset. |
Maximum Digital Resolutions | 1920x1200 |
Supported Resolutions | Widescreen(16/32 bit): 1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1360x768, 1280x800, 1280x768, 1280x720 Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x864, 1024x768, 800x600 |
Wide Screen Supported | Yes |
Connector(s) | |
Connector A | 1 - USB 3.0 A (9 pin; SuperSpeed) Male |
Connector B | 1 - HDMI (19 pin) Female |
1 - USB 3.0 A (9 pin; SuperSpeed) Female | |
Software | |
Microsoft WHQL Certified | Yes |
OS Compatibility | Windows® 10 (32/64) Windows 8 / 8.1 (32/64) Windows 7(32/64) Windows Vista (32/64) Windows XP (32/64) |
Special Notes / Requirements | |
Note | Connect a maximum of five USB32HDEH adapters on a single PC - See manual for system requirements |
System and Cable Requirements | CPU: i3 Dual core 2.8GHz RAM: 2GB or higher Full HD Video: CPU: Quad Core 2.4GHz or Higher (i5 recommended) RAM: 4GB or higher |
Power | |
Power Source | USB-Powered |
Environmental | |
Humidity | < 85% non-condensing |
Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Storage Temperature | -10°C to 75°C (14°F to 167°F) |
Physical Characteristics | |
Cable Length | 6.3 in [160 mm] |
Color | Black |
Enclosure Type | Plastic |
Product Height | 0.7 in [17 mm] |
Product Length |
![]() |
