Audio | Yes |
Chipset ID | DisplayLInk - DL3500 |
Memory | 512MB DDR II |
Output Signal | HDMI |
USB Pass-Through | No |
Performance | |
---|---|
Audio Specifications | 5.1-Channel Surround (48Khz) |
General Specifications | This USB video adapter uses a DisplayLink family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a Trigger or Fresco family chipset. |
Maximum Digital Resolutions | 1920x1200 / 1080p |
Note | If using OS X 10.8, Apple update 10.8.3 must be installed before installing DisplayLink software. 10.8.3 fixes several serious OS X bugs exposed when DisplayLink software is installed. |
Supported Resolutions | Widescreen(16/32 bit): 1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1360x768, 1280x800, 1280x768, 1280x720 Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x864, 1024x768, 800x600 |
Wide Screen Supported | Yes |
Connector(s) | |
Connector A | 1 - USB 3.0 A (9 pin; SuperSpeed) Male |
Connector B | 1 - HDMI (19 pin) Female |
Software | |
OS Compatibility | Windows® 10 (32/64) 8/8.1 (32/64), 7 (32/64bit), Vista(32/64), XP(32/64), 2000 (Aero 3D interface supported) Apple® OSX El Capitan (10.11), Yosemite (10.10), Mavericks (10.9) Mountain Lion (10.8), Lion (10.7), Snow Leopard (10.6) |
Special Notes / Requirements | |
System and Cable Requirements | 1~2 USB Displays Office Application: CPU: i3 Dual core 2.8GHz RAM: 2GB or higher Full HD Video: CPU: Quad Core 2.4GHz or Higher (i5 recommended) RAM: 4GB or higher |
Not intended for gaming | |
Power | |
Power Source | USB-Powered |
Environmental | |
Humidity | 20°C to 80°C (68°F to 176°F) |
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
Storage Temperature | -5°C to 40°C (23°F to 104°F) |
Physical Characteristics | |
Cable Length | 3 ft [0.9 m] |
Color | Black |
Enclosure Type | Plastic |
Product Height | 0.8 in [20 mm] |
Product Length |
![]() |
