| Audio | Yes |
| Chipset ID | DisplayLink - DL5500 |
| Output Signal | DisplayPort |
| Ports | 1 |
| USB Pass-Through | No |
| Performance | |
|---|---|
| General Specifications | This USB video adapter uses a DisplayLink family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a Trigger or Fresco family chipset. |
| Maximum Digital Resolutions | 4K x 2K @ 30Hz |
| Supported Resolutions | Widescreen(16/32 bit): 3840×2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720 Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480 |
| Wide Screen Supported | Yes |
| Connector(s) | |
| Connector A | 1 - USB 3.0 A (9 pin; SuperSpeed) Male |
| Connector B | 1 - DisplayPort (20 pin) Female |
| Software | |
| OS Compatibility | Windows® 10 (32/64), 8/8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000 (Aero 3D interface supported) Apple® OSX El Capitan (10.11), Yosemite (10.10), Mavericks (10.9) Mountain Lion (10.8), Lion (10.7), Snow Leopard (10.6) |
| Power | |
| Power Source | USB-Powered |
| Environmental | |
| Humidity | <85% RH Non-Condensing |
| Operating Temperature | 10°C to 40°C (50°F to 104°F) |
| Storage Temperature | -10°C to 80°C (14°F to 167°F) |
| Physical Characteristics | |
| Cable Length | 2.5 in [63.5 mm] |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 0.6 in [15 mm] |
| Product Length | 3.5 in [90 mm] |
| Product Weight | 2.3 oz [64 g] |
| Product Width | 1.8 in [45 mm] |
| Packaging Information | |
| Shipping (Package) Weight | 0.5 lb [0.2 kg] |
| What's in the Box | |
| Included in Package | 1 - USB 3.0 to DisplayPort Video Card |
| 1 - Software Installation Disc | |
|
|
