WAN (2,5Gb/s): 1 port, LAN (2,5Gb/s): 4 port, USB-C: 1db, energiafelhasználás: 9,6W, fehérWAN (2,5Gb/s): 1 port, LAN (2,5Gb/s): 4 port, USB-C: 1db, energiafelhasználás: 9,6W, fehér
| Mechanical |
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") |
| Weight | 520 g (1.1 lb) |
| Enclosure material | Polycarbonate |
| Resistance | IK04 |
| Hardware |
| Processor | Quad-core ARM® Cortex®-A53 at 1.5 GHz |
| Memory information | 2 GB DDR4 |
| Management interface | Ethernet
Bluetooth |
| Networking interface | LAN:
(4) 2.5 GbE RJ45 ports
WAN:
(1) 2.5 GbE RJ45 port |
| Power method | USB type C (5V/3A) |
| Supported voltage range | 100–240V |
| Max. power consumption | 9.6W |
| LED | Ethernet
White: link/activity |
| Button | (1) Factory reset |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features |
| Performance | WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Internet quality and outage reporting |
| Next-generation security | Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall |
| Advanced networking | License-free SD-WAN*
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport* and Identity Enterprise VPN**
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IPv6 ISP support
*When paired with a Cloud Key or Official UniFi Hosting.
**When paired with a Cloud Key. |
| Application Requirements |
| UniFi Network | Version 8.1.113 and later |
