HÁLÓZAT
Biztonság Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Szabvány TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
API ONVIF
Simultaneous Live View 4 Main Streams & 3 Sub-Streams,
or 3 Main Streams & 5 Sub-Streams
ÁLTALÁNOS
Certifications CE, FCC, RCM, BSMI, VCCI, RoHS
Méret (Ma x Sz x Mé) 123 × 123 × 83 mm
Material Plastic
Tömeg 195 g
General Features Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Power Requirements 12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)
KAMERA
Képérzékelő 1/2.7” Progressive Scan CMOS
Optika 4 mm / 2.8 mm
Aperture 4 mm: F2.4
2.8 mm: F2.0
Lens Mount M12
Látószög 4 mm, horizontal FOV: 92°, vertical FOV: 48°, diagonal FOV: 114°
2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 125°
Day/Night Mechanism IR Cut Filter
IR Working Distance 30m
Min. szükséges megvilágítás Color: 0.1 Lux@F2.0 ; 0 Lux with IR
Forgatási/döntési szög Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360°
Digital Noise Reduction 3D DNR
WDR DWDR
VIDEÓ/KÉP
Videó tömörítés Main stream: H.265/H.264
Sub-Stream: H.265/H.264
Kép frissítés (frame) és felbontás Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720, 704x576, 640x480, 352x288, 320x240
Képbeállítás Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Image Enhancement BLC/3D DNR/Prevent Overexposure to Infrared Light
Video Bit Rate 64 Kbps to 6 Mbps
SMART FEATURE-SET
Smart Event Area Intrusion Detection, Line-Crossing Detection
Basic Event Motion Detection, Video Tampering Detection, Exception ( illegal login)
Linkage Method Trigger Notification: ONVIF, HTTPS
Region of Interest 1 Region
FIZIKAI KEZELŐFELÜLET
Hálózati csatlakozás 1 RJ45 10/100M Self-Adaptive Ethernet Port
Gomb -
Video Output -
