1/3.2'' Progressive Scan CMOS Not Starlight Sensor
LensFocal Length: 4 mm
Aperture: F2.0
Field of View: 87° (Diagonal), 74°(Horizontal), 40°(Vertical)
Pan Mechanical Range: 340° (360° Pan Coverage)
Tilt Mechanical Range: 70° (110° Tilt Coverage)
850 nm IR LED (40 ft / 12 m)
Interface & Button1× RESET Button
1× MicroSD Card Slot (Up to 512 GB)
1920 × 1080 px
Digital ZoomSupports 10.8x zoom
Frame Rate15/20/25/30 fps ( 15fps by default)
Video CompressionH.264
Live ViewYes
Image Enhancement/
Audio Input & OutputBuilt-in microphone and speaker
Audio Communication2-way audio
Siren Volume88dB (Level measured at 4-inch/10-cm distance)
Video & Audio Local StorageMicro SD card slot
(Supports up to 512GB)
MERCUSYS Camera Care Cloud Storage Services (Subscription required)
Storage Security128 bit AES encryption with SSL/TLS
Software Network ConnectivityConnect via Wi-Fi
Wireless Connectivity11Mbps(802.11b)
54Mbps(802.11g)
72.2Mbps(802.11n)
/
RTSPYes
ONVIFYes
Network Power Source9V DC Power Adapter
Input Voltage100-240VAC, 50/60Hz, 0.3A
Output Voltage9.0V/0.6A
Power Sensor/
AI DetectionMotion detection
Person Detection
Baby Crying Detection
Yes
*Only works with Motion Detection.
System Notification
Detection & Notifications Smart IntegrationGoogle Assistant, Amazon Alexa
Weather Resistance/
Mounting OptionsTabletop
Ceiling-Mounted
0 ºC ~ 40 ºC (32...






|
