beépíthető meghajtók száma: 1db, SATA3, USB2.0, D-Sub: 1db, HDMI kimenet: 1db, LAN (100Mb/s): 5db, 4-csatornás, PoE: 4db, H.265+, feketebeépíthető meghajtók száma: 1db, SATA3, USB2.0, D-Sub: 1db, HDMI kimenet: 1db, LAN (100Mb/s): 5db, 4-csatornás, PoE: 4db, H.265+, fekete
| HÁLÓZAT |
| Szabvány | TCP/IP, DHCP, DNS, NTP, UPnP |
| Incoming Bandwith | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| ÁLTALÁNOS |
| Csomagolás tartalma | VIGI Network Video Recorder
Power Adapter
HDD Screws
Mouse
Quick Installation Guide |
| Operating Temperature | -10–55 °C |
| Méretek (Sz x Mé x Ma) | 246.2 × 148.2 × 45 mm |
| Külső tápellátás | 53.5V DC/1.31A |
| Power Consumption | 4.25 W (without disk) |
| VIDEÓ/KÉP |
| Video Input | 4-Channel IP Video Input, up to 8MP Resolution |
| Recording Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/
DCIF/2CIF/CIF/QCIF |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz,
1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz,
1024x768/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz,
1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz,
1280x720/60Hz |
| DECODING |
| Decoding Format | H.265+/H.265/ H.264+/H.264 |
| Live View/Playback Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/
DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 4 Channel |
| Capability | 2-ch @ 8MP, 4-ch @ 4MP |
| HARD DISK |
| SATA | 1 SATA Interface |
| Capacity | Up to 10 TB |
| FIZIKAI KEZELŐFELÜLET |
| Hálózati csatlakozás | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
