Asus ROG-STRIX-RTX4090-O24G WHITE
Asus GeForce RTX 4090 24GB GDDR6X ROG Strix White OC Edition 2xHDMI 3xDP - ROG-STRIX-RTX4090-O24G WHITE

Processzor
Grafikus processzor család	NVIDIA
Grafikus processzor	GeForce RTX 4090
CUDA	Igen
CUDA magok	16384
Processzor boost órajel	2 610 Mhz
Kijelzők max. száma videókártyánként	4
Memória
Diszkrét grafikus adapter memória	24 GB
Grafikus adapter memóriatípusa	GDDR6X
Memóriabusz	384 bit
Csatlakozók és csatlakozási felületek
Csatlakozófelület típusa	PCI Express 4.0
HDMI portok mennyisége	2
DisplayPort száma	3
DisplayPort verzió	1,4000000
Kialakítás
Hűtés típusa	Aktív
Bővítőhelyek száma	3,5
Teljesítmény
HDCP verzió	2.3

ROG Strix GeForce RTX 4090 24GB GDDR6X White OC Edition

ROG Strix GeForce RTX™ 4090 24GB GDDR6X White OC Edition with DLSS 3 and chart-topping thermal performance

• NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
• 4th Generation Tensor Cores:  Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2X ray tracing performance
• OC mode: 2640 MHz (OC mode)/ 2610 MHz (Default mode )
• Axial-tech fans  scaled up for 23% more airflow
• New patented vapor chamber  with milled heatspreader for lower GPU temps
• 3.5-slot design:  massive fin array optimized for airflow from the three Axial-tech fans
• Diecast shroud, frame, and backplate  add rigidity and are vented to further maximize airflow and heat dissipation
• Digital power control  with high-current power stages and 15K capacitors to fuel maximum performance
• Auto-Extreme  precision automated manufacturing for higher reliability
• GPU Tweak III  software provides intuitive performance tweaking, thermal controls, and system monitoring

ROG Strix GeForce RTX 4090 24GB GDDR6X White OC Edition



Graphic Engine

NVIDIA ® GeForce RTX™ 4090

Bus Standard

PCI Express 4.0

OpenGL

OpenGL ® 4.6

Video Memory

24GB GDDR6X

Engine Clock

OC mode: 2640 MHz Default mode: 2610 MHz (Boost Clock)

CUDA Core

16384

Memory Speed

21 Gbps

Memory Interface

384-bit

Resolution

Digital Max Resolution 7680 x 4320

Interface

Yes x 2 (Native HDMI 2.1a)

Yes x 3 (Native DisplayPort 1.4a)

HDCP Support Yes (2.3)

Maximum Display Support

4

NVlink/ Crossfire Support

No

Accessories

1 x Collection Card​ 1 x Speedsetup Manual​ 1 x Adapter Cable​ (1 to 4) 1 x ROG White Graphics Card Holder 1 x ROG White Velcro Hook & Loop 1 x Thank you Card 1 x ROG Ring

Software

ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.

Dimensions

357.6 x 149.3 x 70.1mm

Recommended PSU

1000W

Power Connectors

1 x 16-pin

Slot

3.5 Slot

AURA SYNC

ARGB
