Spire SP-ATX-600W-80

Spire SP-ATX-600W-80
600w 80+ eagleforce

SHORT SPECIFICATIONS

• 80PLUS certified
• Compliance with Energy Star & Blue Angel
• ATX Ver.2.31 Specification Compliant
• Sleeved flat cables and EZ-Connectors
• EMI Shielded VGA/HDD and Power connectors
• Supports the newest Intel & AMD based systems
• 120mm silent DC fan PWM fan
• Fan speed Variable by temp-controller
• Completely silent 10.0 dBA up to 45C / 113F
• Active Power Factor Correction (APFC)
• High Efficiency (86%) up to 30% less power consumption
• I/O/OVP/OLP and SCP Short Circuit- Overload- Over Power- & current-Protection
• Output cables:
  20+4P *1, 500mm
  SATA+SATA+IDE *1, 500mm
  IDE+IDE+SATA *1, 500mm
  IDE+SATA+SATA *1, 500mm
  P8 (4+4) *1, 600mm
  P6 (2+4) *2, 600mm
• 2 year manufacturer warranty

Unit Weight1.8Unit Dimension (cm)14 x 15 x 8.6Form Factor TypeATXAccessories1. User manual 2. Mounting set screws and includesAuto Fan SpeedYesBearing TypeSleeveBudgetNoCable Length500mmCable TypeFlat - SleevedCertification80PLUSColorblackConnectors

• 1* 20+4P, 500mm
• 1* P8 (4+4) 500mm
• 1* P6 (2+4) 600mm
• 1* SATA+SATA+IDE, 500mm
• 1* IDE+IDE+SATA, 500mm
• 1* IDE+SATA+SATA, 500mm

Cooling12V DCDual Rail 12VYesEfficiency80 PLUS * CertifiedFan Size (cm)12 x 12 x 2.5Fan TypeSilent - BlackFeaturesOCP / OVP / UVP / OPP / OTP / SCPFrequency50~60HzGamingYesHold Up Timet5>17 mS at 100% LoadHousingSteelLED FanNoLife Expectancy (HRS)100.000MaterialSPCCMaterial Thickness (mm)0.8Modular CablesNoNoise Level (dBA)27.0Nominal Power (w)600Operating Temperature (°C)0 ~ 70Packaging Includes

• User manual QR code
• Mounting screws
• Power lead cable

PackagingBrown cartonPackaging TypeRetail boxP.G. Signal100-500msRated Current (A)230VAC, 4ARemarkCE/ROHS/WEEESilentYesSpecificationsV2.31Storage Temperature (°C)-20 ~ 40Total Output Power / RMS (W)600Voltage AC (INPUT)200 ~ 240Voltage Protection

• +12V trip point 13.4V - 15.6V
• +5V trip point 5.74V - 7.0V
• +3.3V trip point 3.76V - 4.3V

Warranty2 years
