| Bus Type | USB 2.0 |
| Chipset ID | FTDI - FT232RL |
| Interface | Serial |
| Port Style | External Hub |
| Ports | 8 |
| Performance | |
|---|---|
| Data Bits | 7, 8 |
| FIFO | 4096 byte Transmit and Receive |
| Max Baud Rate | 921.6 Kbps |
| Maximum Data Transfer Rate | 921.6 Kbps |
| MTBF | 146,300 Hours |
| Parity | Odd, Even, Mark, Space, None |
| Serial Protocol | RS-232 |
| Stop Bits | 1, 2 |
| Connector(s) | |
| External Ports | 1 - USB B (4 pin) Female |
| 8 - DB-9 (9 pin; D-Sub) Male | |
| Software | |
| OS Compatibility | Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000, CE Windows Server® 2012, 2008 R2, 2003, 2000 Mac OS® 10.x (tested up to 10.11) Linux 2.4.x/ 2.6.x |
| Indicators | |
| LED Indicators | 8 - Each, Tx/Rx Activity indicators |
| Power | |
| Input Current | 250 mA |
| Input Voltage | 5 DC |
| Plug Type | M |
| Power Source | USB-Powered |
| Environmental | |
| Humidity | 5~95% RH |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Steel |
| Product Height | 1.7 in [43.2 mm] |
| Product Length | 7.1 in [180 mm] |
| Product Weight | 19.2 oz [544 g] |
| Product Width | 3.9 in [100 mm] |
| Packaging Information | |
| Shipping (Package) Weight | 1.9 lb [0.9 kg] |
|
|
