Intel CM8071504821014
Core i5-14600kf processzor 24 mb smart cache

Essentials

• Product Collection Intel® Core™ i5 Processors (14th gen)
• Code Name Products formerly RAPTOR LAKE
• Vertical SegmentDesktop
• Processor Number i5-14600K
• Lithography Intel 7
• Use Conditions PC/Client/Tablet, Workstation
• Recommended Customer Price $319.00-$329.00

Sign in ? with your CNDA account to view additional SKU details.

CPU Specifications

• Total Cores 14
• # of Performance-cores6
• # of Efficient-cores8
• Total Threads 20
• Max Turbo Frequency 5.3 GHz
• Performance-core Max Turbo Frequency 5.3 GHz
• Efficient-core Max Turbo Frequency 4 GHz
• Performance-core Base Frequency3.5 GHz
• Efficient-core Base Frequency2.6 GHz
• Cache 24 MB Intel® Smart Cache
• Total L2 Cache20 MB
• Processor Base Power 125 W
• Maximum Turbo Power 181 W

Supplemental Information

• Marketing StatusLaunched
• Launch Date Q4'23
• Embedded Options Available No

Memory Specifications

• Max Memory Size (dependent on memory type) 192 GB
• Memory Types Up to DDR5 5600 MT/s
  Up to DDR4 3200 MT/s
• Max # of Memory Channels 2
• Max Memory Bandwidth 89.6 GB/s
• ECC Memory Supported? ‡ Yes

GPU Specifications

• Processor Graphics? ‡ Intel® UHD Graphics 770
• Graphics Base Frequency 300 MHz
• Graphics Max Dynamic Frequency 1.55 GHz
• Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1
• Execution Units 32
• Max Resolution (HDMI) ‡ 4096 x 2160 @ 60Hz
• Max Resolution (DP)‡ 7680 x 4320 @ 60Hz
• Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz
• DirectX* Support 12
• OpenGL* Support 4.5
• OpenCL* Support 3.0
• Multi-Format Codec Engines 2
• Intel® Quick Sync Video Yes
• Intel® Clear Video HD Technology Yes
• # of Displays Supported? ‡ 4
• Device ID0xA780

Expansion Options

• Direct Media Interface (DMI) Revision4.0
• Max # of DMI Lanes8
• Scalability1S Only
• PCI Express Revision 5.0 and 4.0
• PCI Express Configurations? ‡ Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes 20

Package Specifications

• Sockets Supported FCLGA1700
• Max CPU Configuration1
• Thermal Solution Specification PCG 2020A
• T JUNCTION 100°C
• Package Size45.0 mm x 37.5 mm

Advanced Technologies

• Intel® Gaussian & Neural Accelerator 3.0
• Intel® Thread Director Yes
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
• Intel® Speed Shift Technology Yes
• Intel® Turbo Boost Technology? ‡ 2.0
• Intel® Hyper-Threading Technology? ‡ Yes
• Intel® 64? ‡ Yes
• Instruction Set 64-bit
• Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States Yes
• Enhanced Intel SpeedStep® Technology Yes
• Thermal Monitoring Technologies Yes
• Intel® Volume Management Device (VMD) Yes

Security & Reliability

• Intel® Standard Manageability (ISM)? ‡ Yes
• Intel® Control-Flow Enforcement Technology Yes
• Intel® AES New Instructions Yes
• Secure Key Yes
• Intel® OS GuardYes
• Execute Disable Bit? ‡ Yes
• Intel® Boot Guard Yes
• Mode-based Execute Control (MBEC) Yes
• Intel® Virtualization Technology (VT-x)? ‡ Yes
• Intel® Virtualization Technology for Directed I/O (VT-d)? ‡ Yes
• Intel® VT-x with Extended Page Tables (EPT)? ‡ Yes
