| Socketcompatibility | Intel LGA2011-0 & LGA2011-3(SquareILM), LGA1156, LGA1155, LGA1150 & AMD AM2, AM2+, AM3,AM3+, FM1, FM2, FM2+ (backplaterequired) |
| Height (without fan) | 51mm |
| Width (without fan) | 95mm |
| Depth (without fan) | 95mm |
| Height (with fan) | 65mm |
| Width (with fan) | 95mm |
| Depth (with fan) | 95mm |
| Weight (without fan) | 340g |
| Weight (with fan) | 413g |
| Material | Copper(base and heat-pipes), aluminium (cooling fins), soldered joints& nickel plating |
| Max. TDP | - |
| Fan compatibility | 92x92x14,92x92x25 |
| Scope of Delivery | NF-A9x14PWM premium fan Low-Noise Adaptor (L.N.A.) NT-H1 high-grade thermal compound SecuFirm2™ Mounting Kit Noctua Metal Case-Badge |
| Fan specifications | |
| Model | NoctuaNF-A9x14 PWM |
| Bearing | SSO2 |
| Max. Rotational Speed (+/- 10%) | 2500RPM |
| Max. Rotational Speed with L.N.A. (+/- 10%) | 1800RPM |
| Min. Rotational Speed (PWM, +/-20%) | 600RPM |
| Max. Airflow | 57,5m³/h |
| Max. Airflow with L.N.A. | 40,8m³/h |
| Max. Acoustical Noise | 23,6dB(A) |
| Max. Acoustical Noise with L.N.A. | 14,8dB(A) |
| Input Power | 2,52W |
| Voltage Range | 12V |
| MTBF | >150.000 h |
