? Application ForIntelLGA1851/1700/1200/115XAMDAM5/AM4Technical Spec Net Weight 1900 g Radiator Dimensions 402×120×27 mm(L×W×H) Radiator Material Aluminum Tube length 410 mm Pump Dimensions 89×76×64 mm(L×W×H) Pump Speed 2500~3400 RPM±10% Pump Connector 4-pin PWM Pump Rated Voltage 12 VDC Pump Rated Current 0.29 A Pump Power Consumption 3.48 W Fan Dimensions 120×120×25 mm(L×W×H) Fan Speed 500~2150 RPM±10% Fan Airflow 55 CFM Fan Air Pressure 2.82 mmAq Fan Noise ≤32 dB(A) Fan Connector 4-pin PWM Bearing Type Fluid Dynamic Bearing Fan Rated Voltage 12 VDC Fan Rated Current 0.15 A Fan Power Consumption 1.8 W LED Type Addressable RGB LED LED Connector 3-pin(+5V-D-G) LED Rated Voltage 5 VDC LED Power Consumption 2.4 W(PUMP)/ 8.25 W(FAN×3) Display Type LED Digital Display Display Module Rated Current 0.08 A±10% Display Module Rated Voltage 5 VDC Display Module Power Consumption 0.4 W Display Area 53.9×49.15 mm EAN 6933412729815 P/N R-LQ360-WHASMC-G-1
