| Chipset ID | Jmicron - JM20330 |
| Compatible Drive Types (Type and Rate) | IDE (ATA) |
| Drive Installation | Fixed |
| Drive Size | 2.5in & 3.5in |
| Fan(s) | No |
| LBA support | 48-bit |
| Number of Drives | 1 |
| Connector(s) | |
|---|---|
| Connector Type(s) | 1 - SP4 (4 pin; Small Drive Power) Male |
| Drive Connectors | 1 - IDE (40 Pin; EIDE/PATA) Female |
| 1 - IDE (44 Pin; EIDE/PATA; 2.5" HDD) Female | |
| 1 - LP4 (4 pin; Molex Large Drive Power) Female | |
| Host Connectors | 1 - SATA (7 pin; Data) Plug |
| 1 - SATA Power (15 pin) Plug | |
| Software | |
| OS Compatibility | OS independent; No software or drivers required |
| Environmental | |
| Humidity | 8% ~ 90% RH |
| Operating Temperature | 5°C to 80°C (41°F to 176°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Steel |
| Product Height | 1 in [26 mm] |
| Product Length | 4 in [101 mm] |
| Product Weight | 3.7 oz [104 g] |
| Product Width | 3.1 in [78 mm] |
| Packaging Information | |
| Shipping (Package) Weight | 8.1 oz [230 g] |
| What's in the Box | |
| Included in Package | 1 - SATA to IDE adapter |
| 1 - 40-pin IDE cable | |
| 1 - 40-pin to 44-pin IDE cable with power | |
| 1 - SP4 to LP4 Power cable | |
| 1 - Package of mounting screws | |
| 1 - Instruction Manual |
