| Power | 11000 W |
| Current | 16 A |
| Number of phases | 3 |
| Rated mains frequency (Hz) | 50 |
| Input voltage | 400 V |
| DC leakage current detection | 6 mA DC |
Technical details
| Vehicle connection | Type 2 |
| Mounting style | Wall bracket or optional pedestal |
| Cable length | 4.5 m |
| Built-in display | No |
| LED indicators | Charging |
Other features
| Built-in counter | No |
| Audible alarm | Yes |
Security
| Overvoltage protection | Y |
| Overcurrent protection | Yes |
| Over voltage protection | Yes |
| International Protection (IP) code | IP54 |
| Degree of protection IK | IK08 |
| Grounding system supported | IT TN TT |
| Locking switch with key | Yes |
Features
| Operating temperature (T-T) | -15 - 45 °C |
| Product colour | Black |
| Housing material | Plastic |
Weight & dimensions
| Width | 225 mm |
| Height | 447 mm |
| Depth | 116 mm |
| Weight | 4.6 kg |
Certificates
| Certificates | CE, TUV |
|
|
