Specifications | |
| |
Power supply | 100-240 V AC, ~ 50/60 Hz |
Network power consumption in standby mode | |
Operating temperature | 0 °C-45 °C |
| |
| |
| |
Audio specifications | |
| |
Total speaker output power (max at THD (total harmonic distortion) 1%) | 590 W |
Soundbar output power (max at THD (total harmonic distortion) 1%) | 290 W |
Subwoofer output power (max at THD (total harmonic distortion) 1%) | 300 W |
Soundbar transducer | 4x (46x90)mm racetrack units, 3x 0.75" (20mm) tweeters |
Subwoofer transducer | 10" (260mm) |
Frequency range | 35 Hz - 20 kHz (-6 dB) |
Audio inputs
| 1 optical, Bluetooth, USB (USB playback is only available in the US version. In other versions, USB is for service use only.) |
| |
| |
| |
Dimensions | |
| |
Soundbar Dimensions (W x H x D) | 1017 x 56 x 103.5 mm |
Subwoofer dimensions (W x H x D) | 305 x 440.4 x 305 mm |
Soundbar weight | 2.8 kg |
The weight of the subwoofer | 10 kg |
Package dimensions (W x H x D) | 1105 x 370 x 475 mm |
Package weight | 16.2 kg |
| |
| |
| |
Specifications, control and connection | |
| |
USB port | Type A |
USB power data | 5V DC, 0.5A |
Supported file formats | MP3 |
MP3 codec | MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3 |
MP3 sample rate | 16 - 48 kHz |
MP3 bit rate | 80-320 Kpbs |
Bluetooth version | 5.0 |
Bluetooth profile | A2DP 1.2, AVRCP 1.5 |
Frequency range for Bluetooth transmitter | 2400 MHz-2483.5 MHz |
Bluetooth transmitter power | |
Wi-fi network | IEEE 802.11 a/b/g/n/ac/ax (2.4 GHz/5 GHz) |
2.4G wi-fi transmitter frequency range
| 2412-2472 MHz (2.4 GHz ISM band, US 11 channels, Europe and elsewhere 13 channels) |
2.4G wi-fi transmitter power | |
5G wi-fi transmitter frequency range | 5.15-5.35 GHz, 5.470-5.725 GHz, 5.725-5.825 GHz |
5G wi-fi transmitter power
| 5.15-5.25 GHz |
2.4G wireless transmitter frequency range | 2406 - 2474 MH |
2.4G wireless transmitter power | |
| |
| |
| |
Video specifications | |
| |
HDMI video input | 1 |
HDMI video output (with Enhanced Audio Return Channel, eARC) | 1 |
HDMI HDCP version | 2.3 |
HDR review | HDR10, Dolby Vision |
