| PANEL | |
| |
Screen Size
| 50"
|
Panel Technology
| IPS
|
Back Light Type
| Direct
|
Aspect Ratio
| 16:9
|
Native Resolution
| 3,840 × 2,160 (UHD)
|
Refresh Rate
| 60Hz
|
Brightness
| 400nit (Typ.)
|
Contrast Ratio
| 1,200:1
|
Dynamic CR
| 1,000,000:1
|
Color gamut
| DCI 80%
|
Viewing Angle(H x V)
| 178x178
|
Color Depth
| 10bit, 1.07Billon colors
|
Response Time
| 12ms (G to G)
|
Surface Treatment(Haze)
| 3%
|
Life time
| 30,000Hrs (Min)
|
Operation Hours (Hours/Day)
| 16/7
|
Portrait / Landscape
| Yes / Yes
|
| | |
| | |
| | |
CONNECTIVITY | |
| |
Input
| HDMI (3, HDCP2.2/1.4), RS232C IN (1, 4pin Phone-jack), RJ45 (LAN), USB2.0 Type A (2)
|
Output
| Audio Out, RS232C OUT (1, 4pin Phone-jack)
|
| | |
| | |
| | |
MECHANICAL SPECIFICATION | |
| |
Bezel Color
| Ashed Blue
|
| Bezel Width | Off : 7.3/7.3/7.3/18.4 mm |
| . | On : 12.8/12.8/12.8/19.9 mm
|
Weight(Head)
| 11.7 kg
|
Packed Weight
| 14.6 kg
|
Monitor Dimension(W x H x D)
| 1,121 x 651 x 57.1 mm
|
Carton Dimensions(W x H x D) (Box outer size)
| 1,215 x 775 x 152 mm
|
VESA™ Standard Mount Interface
| 200 x 200 mm
|
| | |
| | |
| | |
KEY FEATURE | |
| |
HW
| Internal Memory 8GB, Wi-Fi Built-in, Temperature Sensor, Auto Brightness sensor, Local Key Operation (Power On/Off only)
|
SW
| webOS ver. (webOS6.0), Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Screen Share, Video Tag (4, Max One HDMI input), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Cisco certi), Crestron Connected), Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
|
| | |
| | |
| | |
| | |
ENVIRONMENT CONDITIONS | |
| |
Operation Temperature
| 0 °C to 40 °C (Portrait Scene : 0 °C to 35 °C)
|
Operation Humidity
| 10 % to 80 %
|
| | |
| | |
| | |
POWER | |
| |
Power Supply
| AC 100-240V~, 50/60Hz
|
Power Type
| Built-In Power
|
| | |
| | |
| | |
POWER CONSUMPTION | |
| |
Typ.
| 105 W
|
Max.
| 150 W
|
BTU (British Thermal Unit)
| 358 BTU/Hr(Typ.), 512 BTU/Hr(Max.)
|
Smart Energy Saving (~70%)
| 66 W
|
DPM
| 0.5 W
|
Power off
| 0.5 W
|
| | |
| | |
| | |
SOUND | |
| |
Speaker
| Yes
|
| | |
| | |
| | |
CERTIFICATION | |
| |
Safety
| CB
|
EMC
| FCC Class "A" / CE
|
ErP / Energy Star
| Yes / Yes
|
| | |
| | |
| | |
SOFTWARE COMPATIBILITY | |
| |
SuperSign CMS
| Yes
|
SuperSign Control / Control+
| Yes / Yes
|
SuperSign WB
| Yes
|
SuperSign Media Editor
| Yes
|
Promota
| Yes (Not available for EU/CIS)
|
LG ConnectedCare
| Yes
|
| | |
| | |
| | |
LANGUAGE | |
| |
OSD
| English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, Arabic, polski
|
| | |
| | |
| | |
ACCESSORY | |
| |
| Basic | Remote Controller(include battery 2ea), Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder |
| . | . |
