Hp 6PA56A4
Hp e27d g4 advanced docking monitor

Display specifications Display size (diagonal) 60.96 cm (24”) Panel active area 51.84 x 32.4 cm Aspect ratio 16:10 Native resolution WUXGA (1920 x 1200 @ 60 Hz)
(The Display can support up to 75Hz refresh for some video modes. The video card of the connected PC must be capable of supporting 75Hz. The preferred Mode is 1920 x 1080 @ 60 Hz.) Resolutions supported

• 1920 x 1200
• 1920 x 1080
• 1680 x 1050
• 1600 x 900
• 1440 x 900
• 1280 x 1024
• 1280 x 800
• 1280 x 720
• 1024 x 768
• 800 x 600
• 720 x 480
• 640 x 480

Pixel pitch 0.27 mm Brightness 300 cd/m² 1 Contrast ratio 1000:1 static

10000000:1 dynamic 1 View angle 178° horizontal

178° vertical Response time 5 ms gray to gray 1,3 Tilt and swivel angle Tilt: -5 to +22°

Swivel: ±45°

Pivot rotation: 90°

Height: 150 mm Display features Anti-glare

In plane switching

Language selection

LED Backlights

On-screen controls

Pivot rotation

Plug and Play

User programmable

Low Haze Physical security Security lock-ready (lock is sold separately) VESA mount

• 100 mm

Connectivity Input connector 1 DVI-D

1 HDMI 1.4

1 DisplayPort™ 1.2

( with HDCP support on DisplayPort™ and HDMI ) Ports 1 analog audio output

3 USB 3.0 (downstream)

1 USB 3.1 Type-C™ (side, downstream, power delivery up to 10 W)

1 USB 3.1 Type-C™ (rear, downstream and upstream, power delivery up to 15 W) 1 Dimensions and weight Weight 7.2 kg
(With stand) Product dimensions without stand (W x D x H) 53.2 x 4.68 x 35.1 cm
(Without stand) Dimensions With Stand (W x D x H) 53.2 x 21.4 x 50.3 cm Power and operating requirements Power supply

• Input voltage: 100 to 240 VAC

Power consumption

• 92 W (maximum)
• 40 W (typical)
• 0.5 W (standby)

Power consumption (on-mode) 36 W Power consumption 53 kWh Power consumption (standby) 0.5 W Power consumption (off-mode) 0.3 W Operating temperature range 5 to 35°C Operating humidity range 20 to 80% RH Energy efficiency class

• B

Environmental

• Arsenic-free display glass
• Mercury-free display backlights
• Low halogen

Energy Efficiency Energy efficiency class

• B

Display size (diagonal) 60.96 cm (24”) Power consumption (on-mode) 36 W Power consumption 53 kWh Power consumption (standby) 0.5 W Power consumption (off-mode) 0.3 W Resolution (native) WUXGA (1920 x 1200 @ 60 Hz) Certification and compliance Certifications and compliances

• BSMI
• CB
• CCC
• CE
• CEL
• cTUVus
• CU
• ErP
• FCC
• ICES
• ISC
• ISO 9241-307
• Mexico CoC
• Microsoft WHQL Certification (Windows 10 and Windows 7)
• MSIP
• RCM
• SmartWay Transport Partnership - NA only
• VCCI
• WEEE
