Display specifications Display size (diagonal) 60.96 cm (24”) Panel active area 51.84 x 32.4 cm Aspect ratio 16:10 Native resolution WUXGA (1920 x 1200 @ 60 Hz)
(The Display can support up to 75Hz refresh for some video modes. The video card of the connected PC must be capable of supporting 75Hz. The preferred Mode is 1920 x 1080 @ 60 Hz.) Resolutions supported
- 1920 x 1200
- 1920 x 1080
- 1680 x 1050
- 1600 x 900
- 1440 x 900
- 1280 x 1024
- 1280 x 800
- 1280 x 720
- 1024 x 768
- 800 x 600
- 720 x 480
- 640 x 480
Pixel pitch 0.27 mm Brightness 300 cd/m² 1 Contrast ratio 1000:1 static
10000000:1 dynamic 1 View angle 178° horizontal
178° vertical Response time 5 ms gray to gray 1,3 Tilt and swivel angle Tilt: -5 to +22°
Swivel: ±45°
Pivot rotation: 90°
Height: 150 mm Display features Anti-glare
In plane switching
Language selection
LED Backlights
On-screen controls
Pivot rotation
Plug and Play
User programmable
Low Haze Physical security Security lock-ready (lock is sold separately) VESA mount
Connectivity Input connector 1 DVI-D
1 HDMI 1.4
1 DisplayPort™ 1.2
( with HDCP support on DisplayPort™ and HDMI ) Ports 1 analog audio output
3 USB 3.0 (downstream)
1 USB 3.1 Type-C™ (side, downstream, power delivery up to 10 W)
1 USB 3.1 Type-C™ (rear, downstream and upstream, power delivery up to 15 W) 1 Dimensions and weight Weight 7.2 kg
(With stand) Product dimensions without stand (W x D x H) 53.2 x 4.68 x 35.1 cm
(Without stand) Dimensions With Stand (W x D x H) 53.2 x 21.4 x 50.3 cm Power and operating requirements Power supply
- Input voltage: 100 to 240 VAC
Power consumption
- 92 W (maximum)
- 40 W (typical)
- 0.5 W (standby)
Power consumption (on-mode) 36 W Power consumption 53 kWh Power consumption (standby) 0.5 W Power consumption (off-mode) 0.3 W Operating temperature range 5 to 35°C Operating humidity range 20 to 80% RH Energy efficiency class
Environmental
- Arsenic-free display glass
- Mercury-free display backlights
- Low halogen
Energy Efficiency Energy efficiency class
Display size (diagonal) 60.96 cm (24”) Power consumption (on-mode) 36 W Power consumption 53 kWh Power consumption (standby) 0.5 W Power consumption (off-mode) 0.3 W Resolution (native) WUXGA (1920 x 1200 @ 60 Hz) Certification and compliance Certifications and compliances
- BSMI
- CB
- CCC
- CE
- CEL
- cTUVus
- CU
- ErP
- FCC
- ICES
- ISC
- ISO 9241-307
- Mexico CoC
- Microsoft WHQL Certification (Windows 10 and Windows 7)
- MSIP
- RCM
- SmartWay Transport Partnership - NA only
- VCCI
- WEEE
