14", 2560x1600, WVA LED, Intel, Ultra 7-155H, 16×, 0,9GHz, 16GB, PCIe M.2, SSD: 1024GB, Intel, Arc Graphics, LAN: 1Gb/s, IEEE 802.11be (Wi-Fi 7), HDMI, DisplayPort, USB4, TPM, háttérvilágításos billentyűzet, ujjlenyomat-olvasó, FreeDOS, magyar14", 2560x1600, WVA LED, Intel, Ultra 7-155H, 16×, 0,9GHz, 16GB, PCIe M.2, SSD: 1024GB, Intel, Arc Graphics, LAN: 1Gb/s, IEEE 802.11be (Wi-Fi 7), HDMI, DisplayPort, USB4, TPM, háttérvilágításos billentyűzet, ujjlenyomat-olvasó, FreeDOS, magyar
| Part No | 90NX06R1-M01660 |
| Sales Model Name | B5404CMA-QN1020 |
| EAN Code | |
| UPC Code | |
| WEEE | 1.11 |
| BASE UNIT | VSNX06R1-BU6211 |
| Operating System | Non-preinstalled OS |
| Office | |
| LCD cover-material | Aluminum |
| LCD cover-color | Star Black |
| Top case-material | Aluminum + MgAl |
| Top case-color | Star Black |
| Bottom case-material | Aluminum |
| Bottom case-color | Star Black |
| Military grade | US MIL-STD 810H military-grade standard |
| Panel Size | 14.0-inch |
| Backlit | LED Backlit |
| OLED | |
| Brightness | 500nits |
| Resolution | WQXGA (2560 x 1600) 16:10 |
| Glare | Anti-glare display |
| Color gamut | DCI-P3: 100% |
| View angle(H/V) | 178/178 |
| Response time(Typ/Max) (ms) | 25/30 |
| Refresh rate | 120Hz |
| Contrast (Typ) | 1500:1 |
| Touch Panel | Non-touch screen |
| Screen-to-body ratio | 84 % |
| Pantone | |
| IPS-level | Wide view |
| VESA CERTIFIED Display HDR | |
| Processor | Intel® Core™ Ultra 7 Processor 155H 1.4 GHz (24MB Cache, up to 4.8 GHz, 16 Cores)
Intel® AI Boost NPU |
| Neural processor | Intel® AI Boost NPU |
| Chipset | N/A |
| Discrete/Share | Share |
| Integrated GPU | Intel® Graphics |
| VRAM | N/A |
| How to upgrade memory | Upgradable
Need to remove bottom/top case |
| Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| On board memory | N/A |
| DIMM Memory | 16GB DDR5 SO-DIMM |
| Total System Memory | DDR5 16GB |
| Storage | 1TB M.2 2280 NVMe™ PCIe® 4.0 SSD
SSD Housing for storage expansion |
| SSD Cache | N/A |
| Front-facing camera | 1080p FHD camera with IR function to support Windows Hello
With privacy shutter |
| Wireless | Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card |
| On board Wireless | |
| WWAN | |
| NumberPad | N/A |
| FingerPrint | FingerPrint |
| Keyboard type | Backlit Chiclet Keyboard |
| I/O ports | 2x USB 3.2 Gen 2 Type-A
2x Thunderbolt™ 4, compliant with USB4, supports display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet
N/A |
| Audio | Dolby Atmos
Built-in array microphone |
| Battery | 63WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal |
| Dimension (WxHxD) | 31.37 x 22.68 x 1.89 ~ 1.90 cm (12.35" x 8.93" x 0.74" ~ 0.75") |
| Weight (with Battery) | 1.34 kg (2.95 lbs) // 63 WHrs battery |
| Weight (w/ 2nd Battery) | |
| Weight (w/ 3rd Battery) | |
| Weight (w/o Battery) | 1.11 kg (2.45 lbs) |
| Security | Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS setup user password
HDD User Password Protection and Security
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A |
