| Bus Type | USB 2.0 |
| Chipset ID | FTDI - FT232RL |
| Interface | Serial |
| Port Style | Cable Adapter |
| Ports | 1 |
| Performance | |
|---|---|
| Data Bits | 7, 8 |
| FIFO | 256 Bytes |
| Max Baud Rate | 921.6 Kbps |
| Parity | None, Odd, Even, Mark, Space |
| Serial Protocol | RS-232 |
| Stop Bits | 1, 2 |
| Connector(s) | |
| Connector Type(s) | 1 - DB-9 (9 pin; D-Sub) Female |
| 1 - USB A (4 pin) Male | |
| Software | |
| OS Compatibility | Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000, 98SE, XP Embedded, CE (4.2+) Windows Server® 2012, 2008 R2, 2003 Mac OS® 10.x (tested up to 10.11) Linux 2.4.x / 2.6.x |
| Special Notes / Requirements | |
| System and Cable Requirements | One available USB 1.1 (or better) port |
| Power | |
| Power Source | USB-Powered |
| Environmental | |
| Humidity | 5~95% RH |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -20°C to 85°C (-4°F to 185°F) |
| Physical Characteristics | |
| Cable Length | 3.3 ft [1 m] |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 0.6 in [16.5 mm] |
| Product Length | 7 in [179 mm] |
| Product Weight | 3.1 oz [88 g] |
| Product Width | 1.3 in [33.5 mm] |
| Packaging Information | |
| Shipping (Package) Weight | 0.5 lb [0.2 kg] |
| What's in the Box | |
| Included in Package | 1 - USB to RS-232 Null Modem Adapter |
| 1 - Driver CD | |
|
|
