Mercusys MB115-4G
N300 wi-fi 4g/lte router

300Mb/s, IEEE 802.11b/g/n (Wi-Fi 4), WAN (100Mb/s): 1 port, LAN (100Mb/s): 4 port, SIM kártya foglalat, 4G/LTE, antennák száma: 4db, energiafelhasználás: 7,65W, fekete300Mb/s, IEEE 802.11b/g/n (Wi-Fi 4), WAN (100Mb/s): 1 port, LAN (100Mb/s): 4 port, SIM kártya foglalat, 4G/LTE, antennák száma: 4db, energiafelhasználás: 7,65W, feketeGarancia: 3 Év Network Type

EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
CN:
FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

Wi-Fi Class

N300

Wi-Fi (2.4 GHz)

300 Mbps

Wireless Standards (Invaild)

IEEE 802.11b/g/n

Frequency

2.4 GHz

Reception Sensitivity

11g 54M: -74.5 dBm
11n HT20 MCS7: -73.5 dBm
11n HT40 MCS7: -70.5 dBm

Transmission Power

< 20 dBm (2.4 GHz)

Wireless Security

WPA-PSK / WPA2-PSK

Wireless Functions

smart connect
WPS
Wireless Schedule
Wireless Clients Statistics

Wireless Dimensions

219 × 140 × 32 mm

(8.62 × 5.51 × 1.26 in)

Interfaces

1× 10/100Mbps LAN/WAN Port

3× 10/100Mbps LAN Ports

1× Nano SIM Card Slot

Antenna

2× External 4G LTE Antennas,
2× External Wi-Fi Antennas

Button

WPS?Reset Button

External Power Supply

9V/0.85A

LED

1× Power
1× Internet
1× LAN
3× Signal

LTE Standard

Cat 4
150/50Mbps DL/UL

Hardware Operation Mode

3G/4G Router
Wireless Router

Cellular Mode

4G Preferred
4G Only
3G Only

Cellular APN

Data Roaming
Network Search
Profile Create
APN Settings
ISP File Upgrade
PIN Management

WAN Mode

Dynamic IP
Static IP
PPPoE
PPTP
L2TP

NAT Forwarding

ALG
Virtual Server
Port Triggering
UPnP
DMZ

Protocols

IPv4, IPv6

Data Settings

Data Statistics
Data Limit

Parental Controls

Time Control
Website Filtering

Guest Network

2.4 GHz Guest Network

DHCP

Server
DHCP Client List
Address Reservation

DDNS

MERCUSYS DDNS
DynDns
NO-IP

SMS

Inbox
New Message
Outbox
Drafts

Security

IPv4 SPI Firewall
Access Control
Service Filtering
IP & MAC Binding
IPv6 Firewall

System Settings ...
