AnnapurnaLabs, an Amazon company Alpine AL314, 4-core, 1.7GHz
CPU Architecture
32-bit ARM
Floating Point Unit
Yes
Encryption Engine
Yes
System Memory
4 GB SODIMM DDR3 (1 x 4 GB)
Maximum Memory
8 GB (1 x 8 GB)
Memory Slot
1 x SO-DIMM DDR3
Flash Memory
512 MB (Dual boot OS protection)
Drive Bay
4x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
Yes
SSD Cache Acceleration Support
Yes
Gigabit Ethernet Port (RJ45)
1
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
1
10 Gigabit Ethernet Port
1 x 10GbE SFP+
Wake on LAN (WOL)
Only the 1GbE port
USB 3.2 Gen 1 port
3
Jumbo Frame
Yes
Form Factor
Tower
LED Indicators
Power, Status, LAN, USB, HDD1-4
Buttons
Power, Reset, USB Auto Copy
Dimensions (HxWxD)
169 × 160 × 219 mm
Weight (Net)
2.01 kg
Weight (Gross)
3.47 kg
Operating temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
Power Supply Unit
90W Adapter, 100-240V
Fan
1 x 120mm, 12VDC
System Warning
Buzzer
Kensington Security Slot
Yes
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test
Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
