MAG A550BN provides players with a safe, reliable, and efficient entry-level power supply option. Its core features include 80 PLUS Bronze certification, DC to DC circuit design, 12V single rail, active PFC, and low-noise fan. The MAG A550BN will be one of the best choices for players who are just getting started with looking into DIY computers. After installation, gamers can immediately enjoy a reliable performance experience without additional settings.
Marketing leírás
80 PLUS BRONZE certified The efficiency of your power supply directly influences your system's performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.
120mm low noise fan The fan's sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.
DC to DC circuit design Adopted DC-DC circuit design reduces the instability of output voltage, and ads stability to the supply of power.
MSI MAG A550BN - Power supply (internal) - ATX12V / EPS12V - 80 PLUS Bronze - AC 100-240 V - 550 Watt - active PFC
EAN:
4719072849603
Gyártói garancia:
60 hónap szerviz garancia
General
Device Type:
Power supply - active Power Factor Correction (PFC) - internal
Specification Compliance:
ATX12V / EPS12V
PSU Form Factor:
ATX
Power Device
Input Voltage:
AC 100-240 V
Frequency Required:
50 - 60 Hz
Power Output Connectors Details:
1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section 5 x 15 pin Serial ATA power 2 x 4 PIN internal power 2 x 8 pin PCI Express power with detachable 2 pin section 1 x 4 PIN mini-power connector
Output Voltage:
+3.3, +5, ±12 V
Power Capacity:
550 Watt
Output Current:
+3.3V - 20 A +5V - 20 A -12V - 0.3 A +5VSB - 2.5 A +12V - 45.5 A
Efficiency:
85%
80 PLUS Certification:
80 PLUS Bronze
Miscellaneous
Cooling System:
120 mm fan
Features:
Overheat protection, over current protection, over voltage protection, overpower protection, short-circuit protection, single 12V rail, DC-DC technology, non-modular
Manufacturer Warranty
Service & Support:
Limited warranty - 5 years
Dimensions & Weight
Width:
15 cm
Depth:
14 cm
Height:
8.6 cm
